SS Water Bag Filter Housing For Water Filtration And Bag Filter Systems-Yuwei Filtration Equipment Co., Ltd.

Introduction

Water bag filter are ideal for filtration jobs with heavy demands on flow rates and space. Water bag filter remove everything from sediment to other solids to some forms of liquid from the water in both commercial use and industrial applications.

The bag filters have a robust design, which makes them suitable for both cold, hot, acid and basic liquids. With their superior holding capacity, high flow rate, and easy replacement, bag filter systems are among the top choices for water filtration.

Water bag filter has several significant advantages. These include:

Filtering large volumes of water at high flow rates
High dirt holding capacity
Withstanding a variety of conditions
Easy to install and replace
One of the most cost-effective methods
Easy to install and maintain

Benefits of water bag filter used for water filtration

Few other products on the market can withstand high flow rates while keeping low cost. Although there are more powerful filtration methods on the market, none of them can achieve the flow rates that bag filters can withstand, nor are they cost-effective.

Specification

Models	No. of filter bags	Filtration Area (m²)	Flow rate (m³/h)	I/O Connections	Max pressure (Mpa)	Housing Diameter (mm)	Total Height (mm)	Housing Height (mm)
DL-2P2S	2	1	70	DN50	0.5	456	1572	1144
DL-3P2S	3	1.5	105	DN80	0.5	508	1592	1190
DL-4P2S	4	2	140	DN100	0.5	558	1632	1244
DL-5P2S	5	2.5	175	DN150	0.5	608	1788	1254
DL-6P2S	6	3	210	DN150	0.5	658	1854	1300
DL-7P2S	7	3.5	215	DN150	0.5	710	1875	1340
DL-8P2S	8	4	280	DN150	0.5	760	1922	1404
DL-10P2S	10	5	350	DN200	0.5	910	2004	1430
DL-12P2S	12	6	420	DN200	0.5	962	2064	1460
DL-14P2S	14	7	490	DN200	0.5	1012	2124	1490
DL-16P2S	16	8	560	DN250	0.5	1112	2146	1512
DL-18P2S	18	9	630	DN250	0.5	1162	2225	1595
DL-20P2S	20	10	700	DN250	0.5	1212	2280	1640
DL-22P2S	22	11	770	DN250	0.5	1366	2320	1694
DL-24P2S	24	12	840	DN300	0.5	1416	2358	1748

The applications of the water bag filter

Bag filtration is a versatile and cost-effective method for filtering large volumes of water at high flow rates. Water bag filter is ideal for commercial, industrial and municipal water filtration applications, these high capacity systems can treat 90-2400 gallons of water per minute, the filters are very suitable for reducing silt, sand, dirt and other types of deposits in water. Such applications include:

Agriculture
Pre-filtration
Brewing
Non-critical cleaning of a final product
Removal of coarse particles which could potentially damage your equipment
Removal of challenging pollutants from a liquid stream
Groundwater
Cooling water
Industrial process water
Wastewater
